BZT-S
FURIMACH
84224000
Feature
1. Total machine is made of stainless steel to resist water.
2. Adjustable cutter pan equips with double-face blade which is long service life by uniquely whirly cutting.
3. Single positioning center pillar achieves more stable label feeding.
4. Label positioning group makes labeling more precision.
5. Touch control system, friendly operation.
6. Optional independent feeding and labeling system make operation easier and cost lower.
7. It adopts PLC programmable system, imported servo motor, servo driver, inverter and sensor etc., which make labeling accurate, fast and stable.
Main Technical Parameter:
Power Source | AC220V 50Hz/60 Hz |
Label O.D. (mm) | ¢80-200 |
Label speed (pcs/min) | 0-80 |
Label Temp. | 30℃—180℃ |
Label Thickness(mm) | 0.033－0.15 |
Air Pressure(Kg/cm2) ) | 5 |
Label Material | PVC, PE film |
Machine Dimension(mm) | L6100×W1200×H2000 |
Machine Weight(Kg) | 400KG |
Feature
1. Total machine is made of stainless steel to resist water.
2. Adjustable cutter pan equips with double-face blade which is long service life by uniquely whirly cutting.
3. Single positioning center pillar achieves more stable label feeding.
4. Label positioning group makes labeling more precision.
5. Touch control system, friendly operation.
6. Optional independent feeding and labeling system make operation easier and cost lower.
7. It adopts PLC programmable system, imported servo motor, servo driver, inverter and sensor etc., which make labeling accurate, fast and stable.
Main Technical Parameter:
Power Source | AC220V 50Hz/60 Hz |
Label O.D. (mm) | ¢80-200 |
Label speed (pcs/min) | 0-80 |
Label Temp. | 30℃—180℃ |
Label Thickness(mm) | 0.033－0.15 |
Air Pressure(Kg/cm2) ) | 5 |
Label Material | PVC, PE film |
Machine Dimension(mm) | L6100×W1200×H2000 |
Machine Weight(Kg) | 400KG |
